Dry Type Transformer
Dry Type Transformer Manufacturer
About Product Manufacturing
iPower is a Dry Type Transformer Manufacturer in Kolkata, West Bengal. Dry Type Transformer don’t use any liquids for insulation. Regular transformers operate with an insulating liquid where the core is immersed in it. The Dry Type Transformers use a different technique and use a pressurized container surrounded by air. We are one of leading Dry Type Transformer Manufacturer in Odisha, Bihar, Jharkhand, Chhattisgarh, Assam. The core is kept inside the pressurized container.
Details of the product
Industries including wind power, chemical, oil, and gas, fire-risk regions, inner-city stations, underground stations, and some environmentally sensitive places could all benefit from the usage of a Dry Type Transformer. The primary and secondary coil windings of the cast resin type are covered in epoxy resin. This indicates strong resilience to conditions that are prone to dampness. This unique quality is referred to as non-hygroscopic. They can be installed outdoors in an IP 45 enclosure. Because of their low loss and low partial discharge, they are more efficient. Better overload capacity is another outcome of all of these. For the same power and voltage rating, the Dry Type Transformer is slightly more expensive than the others. Also if there is a winding failure during operation, say in a Dry Type Transformer, the high voltage and low voltage windings along with the limb have to be changed.
Advantages of Dry Type Transformer
They are extremely safe for the surrounding properties, their operators, and the surrounding community. They work best in places that are moist and polluted. They are very resistant to electrical short circuits. They are simple to install, low maintenance, pollution-free, fire-hazard-free, and have extremely little side clearance. Additionally, they are long-lasting because to their low thermal and dielectric heating. Because there is no liquid inside the Dry Type Transformer, it performs very effectively even during earthquake activity. Despite their high cost, these are quite inexpensive to install in fire and civil defence systems. They provide excellent overflow support.
- The main advantages of Dry Type Transformerare given below.
- Side clearance is less.
- Reduced cost on civil installation works and fire protection systems.
- Safety for people and property.
- Excellent resistance to short circuit currents.
- Environmentally friendly.
- Easy installation.
- Maintenance and pollution-free solution.
- Suited for damp and contaminated areas.
- Excellent capacity to support overloads.
- Excellent performance in case of seismic events.
- Long lasting due to low thermal and dielectric heating.
- No fire hazard.
What Is Dry Type Transformer?
A Dry Type Transformer is one that never uses any protective fluid, even when its center or windings are submerged in it. Or perhaps a stationary tank under pressure from the atmosphere consists of the windings and core. Dry Type Transformers offer many years of reliable, hassle-free benefits with little maintenance. Under normal operating conditions, a Dry Type Transformer, which has no moving parts and may be a completely inactive strong state device, is typically assured to last a long and trouble-free life. Dry Type Transformers provide a reliable and safe power source without any requirement for capture basins, fireproof vaults, or hazardous gas venting.
Types of Dry Type Transformer
- The dry type transformer types. They are
- Cast Resin Dry Type Transformer (CRT)
- Vacuum pressure Impregnated Transformer (VPI)
- Vacuum Pressure Encapsulated (VPE)
- Cast Coil
- Open Wound Transformer
